We support Electrical Industries to be more competitive and access to New Laboratory Infrastructure
To perform various transformer oil testing in in-house facility.
TDL Lab is an ISO/IEC 17025:2017 National Accreditation Board for Testing and Calibration (NABL) approved lab
TransOil Diagnostic Laboratory (TDL), is a privet oil testing laboratory, registered under the MSME of Maharashtra, was promoted by the electrical industries.
These services are provided through its all over India and outside of India like Dubai, and other gulf countries.
Reliability & Trusted Diagnostics
We are India’s leading NABL accredited private laboratory in transformer oil testing as per IEC / IS / ASTM.
Are performing some oil test like Dissolved Gas Analysis (DGA) and Oil Screening Test (OST). OST tests are distributed in three parameter like Physical Test, Electrical Test, and Chemical Test which is as follows –
Which is indicate the presence of free water, insoluble sludge, carbon particles, fibres, dust, or other contaminants.
Furanic Compound Analysis (Furan) test – Basically this test performs to detect the transformer winding paper condition which is how much deteriorates.
Furan analysis of transformer oil measures the concentration of Furanic compounds, which are byproducts of the breakdown of the transformer’s paper insulation, to assess its degradation. This non-invasive test provides a reliable indicator of the solid insulation’s health, allowing for early detection of aging or faults and enabling predictive maintenance to prevent transformer failure. The concentration of furans, particularly 2 furaldehyde, correlates with the insulation’s condition and can be used to estimate its lifespan and the need for intervention.
Fringilla etiam tempor faucibus ullamcorper arcu nulla duis. Magnis faucibus nulla risus laoreet maximus. Diam lorem suscipit nisi imperdiet quis feugiat nec pede mauris vel iaculis. Sociosqu magna mi mollis litora nascetur pharetra.
This non-invasive test provides a reliable indicator of the solid insulation’s health, allowing for early detection of aging or faults & enabling predictive maintenance to prevent transformer failure.
As paper-based cellulosic insulation ages or is subjected to thermal and oxidative stress, it breaks down into oil-soluble compounds called furans.
Furan analysis involves detecting and quantifying these compounds in a sample of transformer oil, typically using High Performance Liquid Chromatography (HPLC).
The most common Furanic compound measured is 2-furaldehyde (2-FAL), as it is the most stable and abundant byproduct of cellulose breakdown.
The amount of Furanic compounds in the oil is directly proportional to the degradation of the paper insulation.
